KJ-3100 – High pressure pipe cleaner

KJ-3100 – High pressure pipe cleaner

The KJ-3100 mobile high-pressure sewer cleaner with petrol engine is specially designed for cleaning and unblocking sewer pipes with a diameter of 50 to 250 mm. Equipped with an extremely flexible, 61 meter long hose, this high-pressure cleaner reliably removes deposits such as sludge, soap residue, dirt and grease. Thanks to the integrated pulsing system, bends and siphons/odour traps can be overcome effortlessly, allowing the hose to penetrate deeper into the pipes.

Characteristics

  • Powerful: Operating pressure of 205 bar and flow rate of 21 l/min for fast, effective cleaning of pipes.
  • Quick start: The 16 hp petrol engine with recoil starter starts easily. Features: On/off switch; fuel supply interlock; choke and throttle control; easily accessible oil filler opening and dipstick.
  • Lightweight hose: Hose with nylon braiding for significant weight reduction and more flexibility without compromising stability. The thrust drives the hose through the line.
  • Complete: The KJ-3100’s removable hose reel eliminates the need to purchase expensive portable hose reels. The standard package is equipped for indoor and remote applications.
  • Practical: Remove the hose reel to make loading into service vehicles easier. Simply tilt the hose reel forward to access the fuel tank and air filter.
  • Maneuverable: In the heavy-duty 205 bar high pressure pipe cleaner category, the RIDGID KJ-3100 is one of the most maneuverable pipe cleaners on the market. Mounted on a special two-wheeled frame, the unit easily fits through standard sized doors and can maneuver through tight corners with ease.
  • Pulse function: Activate the KJ-3100 model’s pulse function to overcome difficult bends and traps.
  • Quality & reliability: Triple pump with corrosion-resistant forged brass head. Thanks to the gearbox, the pump can run at a lower (optimum) speed. The reduced number of fittings, hoses and components minimizes leaks and breakdowns – keeping you in action.
  • Versatile: High-pressure cleaner package and chemical injection system clean spirals, tools and other heavily soiled equipment.



Scope of delivery KJ-3100:

  • Pull and pick nozzles (1⁄4″)
  • Hose reel with spray hose (61m)
  • 3/8″ high pressure hose
  • FV-1 foot pedal for pressure control
  • Spray lance
  • Root cutter nozzle
  • HF-4 hose with quick coupling



Ordering Information

Art.-Nr.
Produktbezeichnung
Eigenschaften
LxBxH & Gewicht


Art.-Nr.:
R37413
Ausführung: complete set
Leistung: 21 litres / 205 bar
Maße: 635 × 712 × 787 mm
Gewicht: 125


Support Docs

Datasheet Download

0
Request for quotation
