Push-Twister nozzles

Push-Twister nozzles

The Push-Twister nozzle has no propulsion, the entire amount of water is available to the rotary pre-jet. Thus, the nozzle can be used on any commercially available high-pressure cleaner and is the perfect solution for pipe blockages in the house connection area.

This nozzle effectively removes the blockage from the connection or inspection door and pushes the dirt into the main duct. The nozzle is also suitable for cleaning drop lines and vertical garbage chutes.

Characteristics

Fields of application:

  • use from DN 70 to 200 mm
  • blockage removal without feed water
  • the perfect solution for all janitorial services
  • the design allows good arc mobility and prevents tilting of the nozzle
  • especially effective in combination with the mobile high pressure device – InRoKa Rohrboy
  • only to be used with special sliding hose
  • not suitable for use with water recovery system

Ordering Information

Art.-Nr.
Produktbezeichnung
Eigenschaften
LxBxH & Gewicht


Art.-Nr.:
1130308
Anschluss: 3/8" female thread
Einsatz ab: 75 - 200 mm
Wasserleistung: from 20 lpm
Betriebsdruck: 75 bar
Schubdüsen: (-)
Vorstrahldüsen: Twister (20 lpm)
Vorstrahlwinkel: 20°
Maße: 83 × 60 × 60 mm
Gewicht: 0.25


Art.-Nr.:
1130313
Anschluss: 3/8" male -- 3/8" female
Länge: 15 m
Betriebsdruck: max. 350 bar
Maße: 15.000 × 20 × 20 mm
Gewicht: 5.00


Art.-Nr.:
1130314
Anschluss: 3/8" male -- 3/8" female
Länge: 20 m
Betriebsdruck: max. 350 bar
Maße: 20.000 × 20 × 20 mm
Gewicht: 6.70


Art.-Nr.:
1130315
Anschluss: 3/8" male -- 1/2" female
Länge: 15 m
Betriebsdruck: max. 350 bar
Maße: 15.000 × 30 × 30 mm
Gewicht: 5.00


Art.-Nr.:
1130302
Anschluss: 3/8" male -- 1/2" female
Länge: 20 m
Betriebsdruck: max. 350 bar
Maße: 20.000 × 30 × 30 mm
Gewicht: 6.70


Art.-Nr.:
1130317
Maße: 500 × 480 × 120 mm
Gewicht: 0.630


0
