RAK-40 drain cleaning machine

RAK-40 drain cleaning machine

The universal drain cleaner unit RAK 40 suitable for all applications is a multi-purpose drain cleaner unit and may be used for DN 30 – 150 mm drains, accepts sectional cables of 16 – 22 mm diameter, or 6, 8 and 10 mm cables if combined with an adapter magazine – in short, it is suitable for all and anything. As all RAK units, it has the unique external clamping jaw system for quick replacement and easy maintenance of the clamping jaw system.

Fields of application:

  • Thanks to its strong motor and high traction, the RAK-40 is ideal for service, industries and removal of challenging blockades.

Characteristics

Clamping jaw system included
The external clamping jaw system facilitates replacement of the clamping jaws. The RAK units need no special tools, you may replace the clamping jaws within a few minutes and continue with your work.

PRCD-SPS switch (safety switch) included
The safety switch (FI adaptor) detects fault currents and disconnects so fast that life threathening accidents are avoided (10 mA trigger current).



Technical data:

  • Pipe diameter: from 30 – 150 mm
  • sectional cable: 6 / 8 / 10 / 16 / 22 mm
  • cables / Working length:
    • 22 mm cable up to 65 m
    • 16 mm cable up to 55 m
  • Motor power: 750 W Input power
  • Voltage: 230 V / 50 Hz
  • Speed: 670 rpm, clockwise / anticlockwise rotation
  • Weight: 22 kg
  • Dimensions (LxWxH): 540 x 220 x 510 mm



Tools-Kit for 22 mm cable:

  • 5x standard cable: Ø 22 mm, 4 m long, with core
  • 5x standard cable: Ø 22 mm, 4 m long
  • 2x cable cage for ø 22 mm cable
  • 1x 4-blade cutter 45 for ø 22 mm cable
  • 1x 4-blade cutter 65 for ø 22 mm cable
  • 1x U-cutter 65 for ø 22 mm cable
  • 1x straight auger for ø 22 mm cable
  • 1x expander cutter 100 for ø 22 mm cable
  • 1x chain knocker with 2 smooth chains for ø 22 mm cable
  • 1x chain knocker with 2 cam chains for ø 22 mm cable
  • 2x coupling pin keys ø 16/22/32 mm
  • 1x drain cleaning mitt, left hand
  • 1x drain cleaning mitt, right hand
  • 1x toolbox

Ordering Information

Art.-Nr.
Produktbezeichnung
Eigenschaften
LxBxH & Gewicht


Art.-Nr.:
14200230
Spiraltyp: 6 mm, 8 mm, 10 mm, 16 mm, 22 mm
Maße: 540 × 220 × 510 mm
Gewicht: 22.00


Art.-Nr.:
14200231
Spiraltyp: 6 mm, 8 mm, 10 mm, 16 mm, 22 mm
Maße: 480 × 170 × 410 mm
Gewicht: 73.00


Art.-Nr.:
14200233
Spiraltyp: 10 mm
Maße: 320 × 200 × 200 mm
Gewicht: 1.70


Art.-Nr.:
14200232
Maße: 4000 × 80 × 80 mm
Gewicht: 2.50
