Motorised cable reels

Motorised cable reels

The RAP200 and RAP300 motorized cable reels enable automatic rewinding when the crawler is retracted. The cable drums are available with a particularly light and kevlar-reinforced camera cable in the 250 m and 350 m versions.

Characteristics

  • sturdy powder-coated frame
  • motorized drive
  • with emergency stop and automatic stop in case of overload
  • as well as synchronized cross guide spindle Winding aid
  • electronic meter counter
  • remote controllable for the most important functions of cable drum, crawler, additional lights and camera probes
  • removable drip tray

Technical data

  • Product designation: RAP200 / RAP300
  • Cable length: 250 meters / 350 meters
  • Cable diameter: 6.8 mm
  • Power supply: 24 V
  • Protection class: IP45

Ordering Information

Art.-Nr.
Produktbezeichnung
Eigenschaften
LxBxH & Gewicht


Art.-Nr.:
7003050
Länge: 250 m
Anwendung: crawler system
Maße: 530 × 220 × 520 mm
Gewicht: 32.5


Art.-Nr.:
7003051
Länge: 350 m
Anwendung: crawler system
Maße: 530 × 440 × 520 mm
Gewicht: 42.5
